Multiple expansion possibilities.
[/ultimate_heading][vc_row_inner css=”.vc_custom_1477367342045{padding-top: 45px !important;}”][vc_column_inner width=”1/3″][vc_custom_heading text=”Works For…” google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][vc_column_text]
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_custom_heading text=”Key Features” google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][vc_column_text]
- Up to 5 years once daily location
- Up to 2 years detailed tracking
- 24/7 Vehicle Location
- Cellular data when in coverage
- Iridium satellite out of cell coverage
- Man Down Pendant (option)
- Wi-Fi, Bluetooth, RF (Flexi-Card)
- RF Asset Tag Gateway (Flexi-Card)
- Ignition + 4 inputs and 2 outputs
- Fuel/Temp/Humidity sensor options
- PLC interfaces: RS232 & RS485
[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_custom_heading text=”Applications” google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][vc_column_text]
[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_column][/vc_row][vc_row][vc_column][/vc_column][/vc_row][vc_row][vc_column][vc_separator][/vc_column][/vc_row][vc_row][vc_column][ultimate_info_table color_scheme=”gray” package_heading=”SPECIFICATIONS” heading_font_family=”font_family:Open Sans|font_call:Open+Sans” heading_font_size=”desktop:40px;”]
| Mechanical Features | |
| Dimensions mm Weight Housing Fitment Operating Temp Range |
L 225 x W 65 x H 30 500gms incl, batteries ABS/Polycarbonate plastic Screw holes & strap slots -40c to 85c |
| POWER | |
| C-Cell Size Batteries Sleep Current |
4 Alkaline Batteries- Industrial recommended 5uA (micro-amps) |
| CONNECTIVITY | |
| Cellular SIM GPS Antenna |
2G/3G HSDPA Single/optional chip for volume orders SIM Cellular antenna tuned by RF laboratories to ensure optimal performance |
| GPS TRACKING | |
| GPS Module GPS /GLONASS Antenna with Low Noise GPS amplifier |
High sensitivity assisted GPS receiver, 72 channel Concurrent GPS/GLONASS Boosted by low-noise amplifier (LNA) Allows operation in garages and “urban canyons” |
| SMARTS | |
| Recovery Mode | Switch from Daily locate to Live Tracking over-the-air |
| Auto-APN | Analyse SIM and detect APN from pre-loaded list |
| Text Message Setup | Setup APN server etc. |
| Mulit-APN on board | Multiple APN’s for roaming |
| AssitNow Offline | Predicts satellite locations |
| Geo-Fences* | Stores on device *arrival and departure alerts *No-go & Keep out areas *Disable communications within safe areas *Reduce power use during shipping & out of range |
| OTHER FEATURES | |
| 3D Accelerometer Event Sensor Internal memory |
Enable quick wake Dete3ct G-force events Flash | 50,000 records |
| OPTIONAL FEATURES | |
| Magnetic Anti Tamper | Detects opening or removal |
| APPROVALS | |
| Type | CE, ICASA, C-TICK |
[/ultimate_info_table][/vc_column][/vc_row]
