H200 GPS Battery Powered Tracking Device

Description

[vc_row][vc_column][ultimate_heading main_heading=”Simply place ‘n trace. No Installation required.” sub_heading_font_family=”font_family:Open Sans|font_call:Open+Sans|variant:300italic” sub_heading_style=”font-style:italic;font-weight:300;” sub_heading_font_size=”desktop:28px;” sub_heading_line_height=”desktop:20px;” main_heading_font_family=”font_family:Open Sans|font_call:Open+Sans|variant:300″ main_heading_style=”font-weight:300;” main_heading_font_size=”desktop:40px;” margin_design_tab_text=””]

Ultra long-life battery powered.

[/ultimate_heading][vc_row_inner css=”.vc_custom_1477367342045{padding-top: 45px !important;}”][vc_column_inner width=”1/3″][vc_custom_heading text=”Works For…” google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][vc_column_text]

• Civil Plant and Equipment
• Vehicles , Trucks & Trailers
• Boats & Quad Bikes
• Traffic Signage & Lightning Rigs
• Generators & Compressors
• Agricultural Equipment
• Shipping Containers & Skips
• Caravans & Campervans
• Mining Equipment

[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_custom_heading text=”Key Features” google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][vc_column_text]

• Up to 5 years once daily location Up to 2 years detailed tracking
• IP67 water & dust proof
• Rugged, robust and low-profile
• Integrated accelerometer
• Switch from “locate” to “track” OTA
• Magnetic tamper detection ( optional)
• Unauthorised movement alert
• Speed & Accident alert

[/vc_column_text][/vc_column_inner][vc_column_inner width=”1/3″][vc_custom_heading text=”Applications” google_fonts=”font_family:Open%20Sans%3A300%2C300italic%2Cregular%2Citalic%2C600%2C600italic%2C700%2C700italic%2C800%2C800italic|font_style:400%20regular%3A400%3Anormal”][vc_column_text]

• Non-powered asset tracking
• Vehicle and fleet tracking
• Shipping Containers & freight
• Trailers & mobile assets
• Logistic management
• Mining equipment
• Asset run hour monitoring
• Protection of assets
• Scheduled maintenance reminders

[/vc_column_text][/vc_column_inner][/vc_row_inner][/vc_column][/vc_row][vc_row][vc_column][/vc_column][/vc_row][vc_row][vc_column][vc_separator][/vc_column][/vc_row][vc_row][vc_column][ultimate_info_table color_scheme=”gray” package_heading=”SPECIFICATIONS” heading_font_family=”font_family:Open Sans|font_call:Open+Sans” heading_font_size=”desktop:40px;”]

Mechanical Features
Dimensions mm Weight Housing Fitment Operating Temp Range	L 225 x W 65 x H 30 500gms incl, batteries ABS/Polycarbonate plastic Screw holes & strap slots -40c to 85c
POWER
C-Cell Size Batteries Sleep Current	4 Alkaline Batteries- Industrial recommended 5uA (micro-amps)
CONNECTIVITY
Cellular SIM GPS Antenna	2G/3G HSDPA Single/optional chip for volume orders SIM Cellular antenna tuned by RF laboratories to ensure optimal performance
GPS TRACKING
GPS Module   GPS /GLONASS Antenna with Low Noise GPS amplifier	High sensitivity assisted GPS receiver, 72 channel Concurrent GPS/GLONASS Boosted by low-noise amplifier (LNA) Allows operation in garages and “urban canyons”
SMARTS
Recovery Mode	Switch from Daily locate to Live Tracking over-the-air
Auto-APN	Analyse SIM and detect APN from pre-loaded list
Text Message Setup	Setup APN server etc.
Mulit-APN on board	Multiple APN’s for roaming
AssitNow Offline	Predicts satellite locations
Geo-Fences*	Stores on device *arrival and departure alerts *No-go & Keep out areas *Disable communications within safe areas *Reduce power use during shipping & out of range
OTHER FEATURES
3D Accelerometer Event Sensor Internal memory	Enable quick wake Dete3ct G-force events Flash | 50,000 records
OPTIONAL FEATURES
Magnetic Anti Tamper	Detects opening or removal
APPROVALS
Type	CE, ICASA, C-TICK
